I10 - BELT TENSION GUAGE

I10 - BELT TENSION GUAGE This Series of Automatic Spring Loaded Tensioners are available in three different design types, and are used to provide continious tension for Roller Chain Drives from 3/8" pitch to 1-1/2" Simple, Duplex & Triplex, via either a Roller Chain plate wheel or Arm Segment and with the additional option of Aluminium Roller that can be fitted to the T and L Series for Tensioning of Vee, Flat and Timing Belt Drives.









Aluminium Arm Rotational T Series



T1-180-250NT2-340-440N



This type can be supplied fitted with any of the following:




Arc Segment for Roller chains



Roller Chain Plate wheel assembly -15 tooth



Aluminium Roller for Vee Belt -Poly Vee Belt , Flat or Timing Belts



Or We can modify Any Drive sprocket or Pulley to suit this Arm










Aluminium Box (Spring)L Series



L1-66-250NL2-89-340NL3-100-450N



This type can be supplied fitted with any of the following:




Arc Segment for Roller chains



Roller Chain Plate wheel assembly -15 tooth



Aluminium Roller for Vee Belt -Poly Vee Belt , Flat or Timing Belts



Or We can modify Any Drive sprocket or Pulley to suit this Arm










Aluminium Box (Spring) LP Series



LP1-66-250NLP2-89-340NLP3-100-450N



These are supplied complete with a Arc Segment for Simplex, Duplex & Triplex Roller Chains











This Series of Automatic Spring Loaded Tensioners are available in three different design types, and are used to provide continious tension for Roller Chain Drives from 3/8" pitch to 1-1/2" Simple, Duplex & Triplex, via either a Roller Chain plate wheel or Arm Segment and with the additional option of Aluminium Roller that can be fitted to the T and L Series for Tensioning of Vee, Flat and Timing Belt Drives.









Picture shows 15 tooth Simplex & Duplex Roller Chain Idler Assembly for use with the T Arm or the L Box Tensioners.









Picture shows Arm Type T with Arch Segment for Roller Chain Tensioning.
